.5Hp Electric Pump with Solenoid Valve 1 Gallon 4 Way Valve Type
Call For Price
- Part Number: JHW5ES05H1GR
- UPC: 00662459946515
- Availability:
Quantity:
Add To Quote
Add To Estimate
Add To Wishlist
Compare Item
Product Overview
.5Hp Electric Pump with Solenoid Valve 1 Gallon 4 Way Valve Type
Specifications
Details
Industrial Category:
Hydraulics
Industrial Subcategory:
Pumps
Industrial Subtype:
Electric Hydraulic Pumps
Country of Origin:
Taiwan
Current Draw:
9 amps
Dimensions (in), C:
17.13
Dimensions (in), D:
5.98
Dimensions (in), E:
6.9
Dimensions (in), G:
4.51
Dimensions (in), H:
12.32
Dimensions, A (in):
16.1
Dimensions, B (in):
12.01
Motor Size:
0.5 hp
Motor Voltage:
115 volts
OG1 Page:
410
Oil Output Flow Rate, 1st Stage (in3/min):
293
Oil Output Flow Rate, 2nd Stage (in3/min):
18
Pressure Rating, (psi), 2nd Stage:
10,000 psi
Pressure Rating, 1st Stage, psi:
350 psi
Used with Cylinder:
Double Acting
Valve Function:
Advance/Hold/Return
Valve Type:
4-way, 3-position
Weight:
61.5 Lbs
Other Details
10 foot hand held remote controls the solenoid valve
2 speed operations allows for faster cylinder advance
Full load starting capabilities
Ideal for applications where a remote control is required
Internal filter keeps contamination from damaging pump
Quiet operation meets OSHA regulations (80dBA)
