Stainless Steel Cylinder 2 In. Bore 12 In. Stroke
Call For Price
- Part Number: 83.977
- UPC: 00774679839772
- Availability:
Quantity:
Add To Quote
Add To Estimate
Add To Wishlist
Compare Item
Product Variations (45)
Specifications
Details
Industrial Category:
Pneumatics
Industrial Subcategory:
Pneumatic System Components
Industrial Subtype:
Air Cylinders
Body, Housing or Frame Material:
Stainless Steel
Bore Size (in):
2
Color:
Silver
Compatible Fluids:
Air
Country of Origin:
US
Cylinder Action Type:
Double
Installation Type:
Nose Mount
Item Quantity:
1
Item Weight (lbs):
3.20
Maximum Fluid Temperature (°C:
93
Maximum Inlet Pressure (PSI):
200
Minimum Fluid Temperature (°C:
-29
Order Minimum:
1
Order Multiple:
1
Order Unit Of Measure:
EA
Package Height (inches):
2.25
Package Length (inches):
19.00
Package Width (inches):
19.00
Product Series:
83
Product Type:
Pneumatic Cylinders
Stroke Length (in):
12
With Exhaust:
Yes
Other Details
303 stainless steel piston rod
304 stainless steel body
Compatible fluid: compressed air only
Double action
Front installation
High strength aluminum alloy piston and cap
Maximum inlet pressure: 250 PSI
Nitrile rubber seals
Oil-impregnated porous bronze piston rod ring
Operating temperature: -29 to 93°
Piano wire spring
