100 mm Aluminum Compact Connection Tee Union S08
Call For Price
- Part Number: 08.942.09
- UPC: 00774679093112
- Availability:
Quantity:
Add To Quote
Add To Estimate
Add To Wishlist
Compare Item
Product Overview
Info & Guides
Specifications
Details
Industrial Category:
Plumbing
Industrial Subcategory:
Pipe Fittings and Couplings
Industrial Subtype:
Aluminum Pipe Fittings
Quick Connect Air Couplings
2nd Inlet Connection Subtype:
Series 08 Fitting
2nd Inlet Connection Type:
V-Clamp or ANSI/ISO Flanged
2nd Inlet Nominal Size (Imperial):
4 in
2nd Inlet Nominal Size (Metric):
100 mm
Body, Housing or Frame Material:
Aluminum
Color:
Black; Blue
Compatible Fluids:
Air; Neutral and Inert Gases
Compatible With Pipe External Diameters (mm):
100
Country of Origin:
IT
Inlet Connection Subtype:
Series 08 Fitting
Inlet Connection Type:
Compression Fitting
Inlet Nominal Size (Imperial):
4 in
Inlet Quantity:
3
Item Height (inches):
12.60
Item Length (inches):
9.65
Item Quantity:
1
Item Weight (lbs):
9.50
Item Width (inches):
6.50
Mechanism or Internal Moving Parts Material:
Stainless Steel
Order Minimum:
1
Order Multiple:
1
Order Unit Of Measure:
EA
Package Height (inches):
12.60
Package Length (inches):
6.50
Package Weight (lbs):
9.50
Package Width (inches):
6.50
Product Series:
08
Product Type:
Unions
Shape:
Tee
With CRN:
Yes
Other Details
Body and Nut: 100% Aluminum, EN AB 46100
Connection Type: compression and V-Clamp or ASME - DIN universal flanged
Double Lobe Seal: NBR with PTFE coating
Gripping Ring: Stainless steel
Has a Canadian Registration Number (CRN)
Maximum Working Pressure: 191 PSI (13 BAR)
PPS model
S08 Compatible Pipe O.D.: 100 mm
Vacuum level: -28.94 in Hg / -0.98 BAR
Working Temperature: -20 to 80°
