20 Ton Body Repair Kit - Super Heavy Duty
Call For Price
- Part Number: 030256
- UPC:
- Availability:
Quantity:
Add To Quote
Add To Estimate
Add To Wishlist
Compare Item
Product Overview
The Strongarm® Super Duty 2 and 3 stage axle jacks cover a wide variety of demands from the trucking, agriculture, fleet, and military sectors. Each is designed for applications where extra capacity or height is required.
Specifications
Details
Industrial Category:
Hydraulics
Industrial Subcategory:
Hydraulic System Components
Industrial Subtype:
Hydraulic Maintenance Sets
Application:
Construction|Farming|Trucking
Attributes:
Double Braided Hydraulic Hose|Auto Air Bleed Pump
Brand:
Strongarm
Capacity (T):
20
Certification:
ASME/PASE 2019
Closed Height (in.):
11.1
Country of Origin:
CN
Diameter - Inner Ram (in.):
2.56
Duty Level:
Super Heavy Duty
Each Qty.:
1
Effective Area (in²):
5.14
Extension Tubes Length (mm/in.):
28.34mm / 1.1"|50mm / 2"|100.39mm / 4.0"|200mm / 7.9"|275.59mm / 10.9"
Extention Tubes Length (in.):
28.34|50|100.39|200|275.59
HTS (Harmonized Tariff Schedule) Code:
6210.10.90.00
Includes:
Pressure Gauge
Inner Pack Qty.:
0
Item Height (inches):
7.87
Item Length (inches):
32.10
Item Quantity:
1
Item Weight (lbs):
151.0000
Item Width (inches):
12.20
Material Finish (Pump Core and Piston Rod):
Chrome Plated
Max. Operating Pressure (PSI):
8567
Model Number:
750SHD
Net Weight (lb.):
48.5
Oil Output Port Thread:
3/8-18 NPT
Ordering Quantity:
1
Output per Stroke (in.) (Ram Cylinder Extended Len:
0.183
Package Quantity:
1
Package UPC:
10059629997670
Ram Capacity (T):
20
Ram Extended Height (in.):
16
Rated Pressure (PSI):
8567
UOM:
EA
UPC:
059629997673
UPC Number:
059629999097
Other Details
Descent metering valve allows for a safe and controlled lowering of the load
Double polished chrome pistons provide tighter tolerances and greater hydraulic seal
Extra-long handle provides easy positioning under lift points
Industrial style casters are ideal for shop or roadside environments
Safety overload system provides added operator safety
