PFERD Knot Wire End Brush 1" Dia. Straight Cup .014 Stainless Steel 1/4" Shank
Call For Price
- Part Number: 79183164
- UPC:
- Availability:
Quantity:
Add To Quote
Add To Estimate
Add To Wishlist
Compare Item
Product Overview
Info & Guides
Aggressive brush. Designed for medium-duty brushing such as deburring, cleaning, derusting and descaling, as well as removing spatter. Brass wire filament brushes are designed for applications like surface finishing on copper or brass workpieces. Compared to steel wire, brass wire is softer and more flexible. For all brushes with brass wire, PFERD uses wire quality CuZn37. Brass wire is temperature-resistant up to 350°F.
Specifications
Details
Industrial Category:
Abrasives
Industrial Subcategory:
Abrasive Wheels, Discs and Brushes
Industrial Subtype:
Abrasive Brushes
Category Level 4:
End Brushes
Applications:
Cleaning
Applications 1:
Deburring
Applications 2:
Removing oxide layers
Country of Origin:
US
Diameter Cup (In):
1.13
Diameter External (In):
1.00
Diameter Filament Material (In):
0.01
Diameter Shank:
1/4 Inch
Drive Types:
Flexible shaft drive
Drive Types 1:
Power drill
Drive Types 2:
Straight grinder
EDP:
83164
Filament Material:
Brass wire (MES)
Item Quantity:
10
Item Weight (kgs):
0.121
MANUFACTURER_TYPE_DESCR:
END STR CUP KT 1X.014 BRASS
Materials that can be worked:
Brass
Materials that can be worked 1:
Copper
Materials that can be worked 2:
Other non-ferrous metals
Materials that can be worked 3:
Zinc
Mounting System:
Shank
Number Of Knots:
12
Optimum RPM:
8000 - 13000 RPM
Order Quanityt:
10
Packaging:
Industrial packaging
Prop 65:
View
Recommendations for use:
Please observe the recommended rotational speeds.
Recommendations for use 1:
Use variable speed power tools to control the spread of the brush.
Recommendations for use 2:
For best performance, use a power tool with a minimum output of 500 watts.
Safety notes:
When clamping the brush, ensure that the shank is clamped as far into the arbor as possible. This especially applies to high rotational speed ranges. The minimum clamping length is 10 mm.
Trim Length (In):
1.00
UNSPNC:
27111907
Other Details
Aggressive brushing action due to tightly-twisted wire knots.
Non-sparking.
Optimal access to hard-to-reach areas such as recesses and drilled holes.
Reduced flare for more precise surface contact.
