![10" L-Clamp](/vendors/7800/large/1895_99326b9d-9380-4c1f-9d5e-02188d2f1ccf.jpeg "10" L-Clamp")
10" L-Clamp
Call For Price
- Part Number: 390506
- UPC: 00059629896624
- Availability:
Quantity:
Add To Quote
Add To Estimate
Add To Wishlist
Compare Item
Product Overview
JLRD Series L-clamps deliver generous clamping pressure and throat depth for a wide range of applications.
Specifications
Details
Industrial Subtype:
Nutsetters
Power Saw Blades
Brand:
JET
Clamping Pressure:
2,640 PSI
Country of Origin:
CN
Duty Level:
Standard
Each Qty.:
1
Harmonized Tariff Code:
8205.70.90.00
Inner Pack Code:
20059629896628
Inner Pack Depth (in.):
2.40
Inner Pack Length (in.):
17.55
Inner Pack Qty.:
2
Inner Pack Weight (lb):
12.3100
Inner Pack Width (in.):
10.65
Item Depth (in):
2.50
Item Length (in):
16.00
Item Weight (lb):
6.0200
Item Width (in):
8.45
Master Pack Code:
10059629896621
Master Pack Depth (in.):
9.96
Master Pack Length (in.):
17.52
Master Pack Qty.:
10
Master Pack Weight (lb):
62.8500
Master Pack Width (in.):
11.04
Material:
Drop Forged Steel
Maximum Opening:
10"
Model Number:
JLRD-10
Order Unit Of Measure:
EA
Pad Style:
Plain
Pallet Qty.:
1
Rail Size:
1-1/4" x 9/16"
Throat Depth:
4-3/4"
Other Details
High carbon Acme threaded spindle is spatter resistant
Nickel-chrome plated rails are heat-formed from cold-drawn profiled steel
Rails, sliding arms, and spindles are heat-treated for strength
Replaceable spindle and pads available
Tempered drop-forged sliding arm reduces clamping set-up time and is ideal for high-volume production work
